性能与特点：
1、主机采用QC11Y系列液压闸式剪板机结构。
2、数控系统选用ESTUN专用剪板机数控系统。
3、后档料丝杆选用进口滚珠丝杆+直线导轨。
4、根据用户需要可选用其它数控系统。
技术参数：
|
名称Parameter/
规格Specification |
可剪板厚
Shearing Thickness
（mm） |
可剪板宽
Shearing Width
（mm） |
剪切角
Shearing Angle
（°） |
行程次数
Number of Stroke
（min-1） |
后挡料范围
Backgauge Rang
（mm） |
主电机功率
Motor Power
（kw） |
|
QC11Y-6×2500 |
6 |
2500 |
|
14-35 |
20-600 |
7.5 |
|
QC11Y-6×3200 |
6 |
3200 |
30'-1°30' |
12-35 |
20-600 |
7.5 |
|
QC11Y-6×4000 |
6 |
4000 |
30'-1°30' |
10-30 |
20-600 |
7.5 |
|
QC11Y-6×5000 |
6 |
5000 |
30'-1°30' |
10-30 |
20-800 |
11 |
|
QC11Y-6×6000 |
6 |
6000 |
30'-1°30' |
8-25 |
20-800 |
11 |
|
QC11Y-8×2500 |
8 |
2500 |
30'-2° |
12-30 |
20-600 |
11 |
|
QC11Y-8×3200 |
8 |
3200 |
30'-2° |
10-30 |
20-600 |
11 |
|
QC11Y-8×4000 |
8 |
4000 |
30'-2° |
8-25 |
20-600 |
11 |
|
QC11Y-8×5000 |
8 |
5000 |
30'-2° |
8-25 |
20-800 |
15 |
|
QC11Y-8×6000 |
8 |
6000 |
30'-2° |
6-20 |
20-800 |
15 |
|
QC11Y-10×2500 |
10 |
2500 |
30'-2° |
12-30 |
20-600 |
11 |
|
QC11Y-10×3200 |
10 |
3200 |
30'-2° |
10-30 |
20-600 |
11 |
|
QC11Y-10×4000 |
10 |
4000 |
30'-2° |
8-25 |
20-600 |
11 |
|
QC11Y-12×2500 |
12 |
2500 |
30'-2° |
10-25 |
20-600 |
15 |
|
QC11Y-12×3200 |
12 |
3200 |
30'-2° |
9-25 |
20-600 |
15 |
|
QC11Y-12×4000 |
12 |
4000 |
30'-2° |
8-20 |
20-800 |
18.5 |
|
QC11Y-12×5000 |
12 |
5000 |
30'-2° |
6-20 |
20-800 |
18.5 |
|
QC11Y-12×6000 |
12 |
6000 |
30'-2° |
5-20 |
20-800 |
22 |
|
QC11Y-12×8000 |
12 |
8000 |
30'-2° |
4-15 |
20-1000 |
30 |
|
QC11Y-16×2500 |
16 |
2500 |
30'-2°30' |
8-20 |
20-800 |
18.5 |
|
QC11Y-16×3200 |
16 |
3200 |
30'-2°30' |
6-20 |
20-800 |
18.5 |
|
QC11Y-16×4000 |
16 |
4000 |
30'-2°30' |
6-20 |
20-800 |
22 |
|
QC11Y-16×6000 |
16 |
6000 |
30'-2°30' |
4-15 |
20-1000 |
30 |
|
QC11Y-20×2500 |
20 |
2500 |
1°-3° |
6-15 |
20-800 |
22 |
|
QC11Y-20×3200 |
20 |
3200 |
1°-3° |
5-15 |
20-800 |
30 |
|
QC11Y-20×4000 |
20 |
4000 |
1°-3° |
4-12 |
20-1000 |
30 |
|
QC11Y-20×6000 |
20 |
6000 |
1°-3° |
4-10 |
20-1000 |
37 |
|
QC11Y-25×2500 |
25 |
2500 |
1°30'-3°30' |
5-15 |
20-800 |
30 |
|
QC11Y-25×3200 |
25 |
3200 |
1°30'-3°30' |
4-15 |
20-800 |
37 |
|
QC11Y-32×2500 |
32 |
2500 |
1°30'-4° |
4-12 |
20-1000 |
45 |
|
QC11Y-32×3200 |
32 |
3200 |
1°30'-4° |
3-12 |
20-1000 |
45 |
|
QC11Y-40×2500 |
40 |
2500 |
2°-4° |
4-10 |
20-1000 |
55 |
|
QC11Y-40×3200 |
40 |
3200 |
2°-4° |
3-10 |
20-1000 |
55 |
|
QC11Y-50×2500 |
50 |
2500 |
2°-4° |
3-10 |
20-1000 |
2×90 |
|
QC11Y-50×3200 |
50 |
3200 |
2°-4° |
3-10 |
20-1000 |
3×90 |
|
QC11Y-60×3200 |
60 |
3200 |
2°-4° |
2-8 |
20-1000 |
4×90 |
由于产品在不断的改进中，样本技术参数如有改动，恕不另行通知，以随机技术文件为准。
Description and specifications given in this catalogs aro subject to modification without notice.
